Low Emission & Eco-friendly: Equipped with a high-standard China IV emission engine, it effectively reduces exhaust pollution in the working faces and roadways of underground mines.
High Reliability: The working devices are made of high-strength steel plates with a large safety factor and longer service life.
High Efficiency & Energy Saving: Adopting a reversed six-link working device, it effectively improves digging force and lifting capacity, resulting in higher efficiency.
Easy Operation: The hydrostatic transmission system provides stepless speed regulation, reducing frequent gear shifting and improving operation comfort.
Comfortable Driving: The height-adjustable driving canopy effectively improves the driver’s operating comfort and trafficability.
Easy Maintenance: The cover parts adopt a gull-wing design and can be opened on both sides for convenient maintenance.
PARAMETERS
Item
|
Unit
|
Parameter
|
Rated Bucket Capacity
|
m³
|
1
|
Rated Load Capacity
|
t
|
2
|
Maximum Digging Force
|
|
50
|
Maximum Traction Force
|
|
53
|
Travel Speed (Forward/Reverse)
|
|
0-10
|
Transport Overall Dimensions
|
m
|
6.36×1.30×1.91(2)
|
Minimum Turning Radius
|
mm
|
2610/4390
|
Overall Machine Weight
|
t
|
7.2±0.5
|
Engine Brand/Model
|
/
|
Cummins B3.9CS4 / Others
|
Engine Power
|
kW
|
81
|
Engine Emission
|
/
|
China IV
|
Frame Wheelbase
|
mm
|
2250
|
Frame Steering Angle
|
°
|
38
|
Full Load Ground Clearance of Frame
|
mm
|
14
|
Minimum Ground Clearance of Frame
|
mm
|
210
|
Frame Swing Angle
|
°
|
8
|
Maximum Lifting Height of Working Device
|
mm
|
1200
|
Minimum Dumping Distance of Working Device
|
mm
|
1180
|
Maximum Lifting Capacity of Working Device
|
kN
|
30
|
Three-Action Integration Time of Working Device
|
s
|
9.2
|
Optional Equipment
|
/
|
1. Centralized Automatic Fire Suppression System
2. Centralized Fire Suppression System
3. Rearview Camera System
4. Dumping Height 1700mm
|
