Rated load: 1.8m³
Operating weight: 10000kg
Rated power: 92kw
|
Item |
Unit |
Parameter |
|
Loader lifting capacity |
KG |
3000 |
|
Operating weight |
KG |
10000 |
|
Rated bucket capacity |
m³ |
1.8 |
|
Max. tractive force |
KN |
97 |
|
Max. breakout force |
KN |
127 |
|
Max. grade ability |
° |
30 |
|
Max. dump height |
mm |
3100 |
|
Max. dump reach |
mm |
1130 |
|
Overall dimension(L×W×H) |
mm |
7180×2350×3230 |
|
Min. turning radius |
mm |
6250 |
|
Engine Model |
/ |
Weichai |
|
Engine Type |
/ |
lnline, water cooled, four stroke |
|
Cylinder-Inner diameter*stroke |
mm |
6-108×130 |
|
Rated power |
kw | 92 |
|
Max. torque |
N.m |
500 |
|
Min fuel consumption |
g/kw.h |
≤213 |
|
Torque converter |
/ |
YJ320B-1 |
|
Gearbox mode |
/ |
Powershift normally engaged straight gear |
|
Gears |
/ |
forward and 1 reverse gears |
|
Max. speed |
km/h |
38 |
|
Wheel base |
mm |
2758 |
|
Wheel tread |
mm |
1800 |
|
Ground clearance |
mm |
400 |
|
System working pressure |
Mpa |
16 |
|
Boom lifting time |
s | 4.83 |
|
Total time |
s |
9.15±0.5 |
|
Fuel tank capacity |
L |
170 |
|
Self-levelling bucket |
/ |
yes |
|
Service brake |
/ |
Air assist disc brake on 4 wheels |
|
Parking brake |
/ |
Manual brake |
|
Tyre model |
/ |
17.5-25 |
|
Front tyre pressure |
Mpa |
0.4 |
|
Rear tyre pressure |
Mpa |
0.35 |
