Rated load: 5000kg
Operating weight: 6660kg
Rated power: 48kw
| Item | Unit | Parameter |
| Driving mode | / | seated |
| Rated capacity | kg | 5000 |
| Load center distance | mm | 500 |
| Power mode | / | Diesel oil |
| Wheelbase | mm | 2100 |
| Travel speed, unladen | km/h | 18.5 |
| Lifting speed, laden | mm/s | 420 |
| Lowering speed, laden | mm/s | 450 |
| Maximum negotiable gradient, laden | % | 20 |
| Self weight (with oil and water) | kg | 6650 |
| Axle load: unloaded, front/rear | kg | 2865/3795 |
| Axle load: loaded, front/rear | kg | 9680/1480 |
| Battery voltage / nominal capacity | V/Ah | 24/80 |
| Rated output / speed | kW/rpm | 48/2300 |
| Rated torque / speed | N·m/rpm | 230/1600 |
| Number of cylinders | / | 4 |
| Bore × Stroke | mm | 98×105 |
| Displacement | cc | 2540 |
| Tyre type | / | pneumatic tyre |
| Wheels number (front/rear) | / | 2/2 |
| Front track | mm | 1180 |
| Rear track | mm | 1190 |
| Tyre (front) | / | 300-15-18PR |
| Tyre (rear) | / | 700-12-14PR |
| Front overhang | mm | 560 |
| Tilt of the mast, front/rear | ° | 6/12 |
| Mast lowered height | mm | 2275 |
| Mast extended height (with backrest) | mm | 150 |
| Overall maximum lift height | mm | 3000 |
| Height, mast extended | mm | / |
| Overhead guard height | mm | 2350 |
| Min. ground clearance (bottom of mast) | mm | 175 |
| Fork size (T×W×L) | mm | 50×150×1070 |
| Truck body length (fork excluded) | mm | 3240 |
| Truck body width | mm | 1480 |
| Turning radius | mm | 3050 |
| Manufacturer | / | CHINA |
| Transmission type | / | Mechanical / Hydraulic |
| Stage (Forward/Reverse) | / | 1/1 (2/2) |
